Artwork Preparation for RFID Cards and Wristbands

Card artwork uses an 85.6 × 54 mm finished format with the approved bleed, safe area and reverse-face content built around the 0.76 mm construction. Wristband artwork starts from the printable, mouldable or weaveable area of the selected body and closure.

A Caribbean visual direction can use sea colour, coral, natural grain or restrained resort typography without making the physical limits disappear. We translate the identity into the manufacturing process instead of forcing one master image across every product.

We place logos, colour fields, numbering and guest-facing text on a product-specific template. The reverse is treated as designed space for operational information, not as the leftover side of the card.

Wood and fibre surfaces can soften fine detail or change contrast; recycled PVC provides a more uniform print field. The proof names the material and finish so an approval cannot be transferred to another body without review.

Moulded, debossed, embossed and printed silicone details have different minimum strokes and colour behaviour. We simplify marks that are too fine for the selected process and show the real placement around the wrist rather than approving a flat logo in isolation.

Size and module location also affect the visible area. A design that looks centred on an open band can rotate out of view when worn, so the product proof includes the fastening position.

A woven band expresses colour through yarn and structure rather than card-style print resolution. Small type, thin outlines and subtle gradients are converted into forms the weave can reproduce consistently.

The closure, tail and credential module interrupt the available field. We map those components before placing entitlement text or a property mark, especially where staff must identify a class at arm’s length.

Numbers, codes and other changing fields are supplied as an approved data file with a defined range and format. We mark them on the proof as variable rather than embedding examples into the fixed artwork.

Each distinct printed design carries a minimum order of 500 pieces. Colour changes used only for access classes are still design changes, so the variant matrix is agreed before production quantities are released.

A brand colour viewed on a bright screen does not become the same colour on recycled PVC, natural wood, plant-based board, silicone and woven yarn. We prepare each proof in the context of its body and agree where a close material translation is acceptable and where a controlled printed match is required.

Island hospitality ranges often use one visual family across room cards, pool bands and staff credentials. We preserve that relationship through named colour references and retained samples, while allowing the surfaces to look like the materials they are. Forcing an artificial identical finish across them would make the range less truthful and harder to reproduce. Approval notes identify any intentional difference so a later reorder does not mistake it for production drift. Each note stays with its product proof.

A screen PDF is the wrong approval when it does not name the body, finish and production method. Fine card typography is wrong for a woven band, and a subtle grain-dependent logo is wrong when the property requires exact contrast on every unit.

We revise the artwork before release rather than ask production to interpret intent. If the supplied logo or wording cannot be reproduced honestly on the chosen product, the product or the artwork must change.
